Obstacle Avoidance LiDAR 270 Degree 25m Type-C TOF OEM TOF

Obstacle Avoidance LiDAR built for detection zones, with 270° scanning, IP65, and stable signal output for catalog use.

Product
SKU: safety-lidars-16 Categoría: Etiquetas: , ,
Comparte tu aprecio

For industrial robots, AGVs, and safeguarded zones, this obstacle avoidance lidar provides 270° scanning with 0.05-8m at 10% reflectivity; up to 25m at >90% sensing.

Product Type

Obstacle Avoidance LiDAR
Sensing Range

0.05-8m at 10% reflectivity; up to 25m at >90%
Scan Angle

270°
Angular Resolution

0.25° / 0.33°
Output Type

NPN or PNP transistor output
Protection Level

IP65
Power Supply

DC9-28V
Scan / Response

15Hz
Regional Groups

16 regional groups
Laser Safety

Class 1 laser, 905nm
